    10 Inch TFT Lcd Display 235 X 143 X 6.8 mm TFT LCD Resistive Touchscreen 1024 X 600 Resolution

    Ask Lasest Price
    Brand Name : Fangsheng
    Model Number : FS-TA10MZXH02-T
    Certification : ISO9001:2015
    Price : Negotiation
    Payment Terms : T/T,Western Union, Paypal, D/A, D/P, L/C, MoneyGram
    Supply Ability : 200K Sets / Month
    Delivery Time : 2 - 5 Working Days
    • Product Details
    • Company Profile

    10 Inch TFT Lcd Display 235 X 143 X 6.8 mm TFT LCD Resistive Touchscreen 1024 X 600 Resolution


    235 X 143 X 6.8 mm TFT LCD Module Transmissive 1024 X 600 Resolution


    Specification : COG-TA10MB1XH-1620190920A(1)suneadable-Model-fancy


    Item

    Contents

    Unit

    Lcd Type

    Tft/Transmissive

    Module Size (w*h*t)

    235.00*143.00*6.8

    Mm

    Active Size (w*h)

    222.72*125.28

    Mm

    Pixel Pitch (w*h)

    0.2175*0.2088

    Mm

    Number Of Dots

    1024*600

    Diver Ic

    Hx8282a+Hx8696a

    Interface Type

    RGB

    Top Polarizer Type

    Anti-Glare

    Recommend Viewing Direction

    12

    o’Clock

    Gray Scale Inversion Direction

    6

    o’Clock

    Colors

    16.7m

    Backlight Type

    24-Dies White Led

    Touch Panel Type

    Resistive


    Our Certificates:

    1 . GB/T19001-2016 idt ISO9001:2015
    2 . CE & ROHS
    3 . SGS of LCD Display



    The Advantages :

    less energy consumption, visibility is sharper in other words has superb quality, physical design, response time, and less eye strain etc… With every great product there are few disadvantages associated, such as, cost and viewing angles.

    The Disadvantages:

    Due to the nature of the design TFT LCD Display may cost a little more than a regular monochrome display. Other disadvantages may arise when the viewing the display at the 6 0’clock direction but in fact the optimal viewing is at the 12’oclock direction this may also lead to inversion which or common in situation like this; however TFT displays are superior and will be in production for years to come.


    FAQ

    1. Are you manufacturer or Trading Company?
    --- We are a LCD display manufactuer and factory is located in Dongguan.

    2. What about the sample lead time?
    ---The customized mono lcd needs 12-16 working days, the TFT lcd needs 2-5 working days.

    3. What is the MOQ?
    --- Generally there have differents minimum qty requirements for different products.

    4.How can I deal with your company?
    ---Online trade is available. We would perfer online trade, there are low handing fee and can protect the payment.

    5.Does the products have any warranty?
    --- Yes, we offer 12 months warranty for our products. Damage due to misuse, ill treatment and unauthorized modifications and repairs are not covered by our warranty.

    6. Does your company offer the custom solution?
    ---Yes, we can offer custom solution if the stardard products couldn’t meet buyer’s requirements.

    7. Can I apply for free samples?
    ---Yes, Please send the inquiry to us and apply for the free samples.
