40 Pins TFT LCD Resistive Touchscreen 4.6 Inch 800 x 320 Resolution STN Positive Type

HongKong Guanke Industrial Limited
Trust Seal
Verified Supplier
Credit Check
Supplier Assessment
Contact Now
    Buy cheap 40 Pins TFT LCD Resistive Touchscreen 4.6 Inch 800 x 320 Resolution STN Positive Type from wholesalers

    Buy cheap 40 Pins TFT LCD Resistive Touchscreen 4.6 Inch 800 x 320 Resolution STN Positive Type from wholesalers
    • Buy cheap 40 Pins TFT LCD Resistive Touchscreen 4.6 Inch 800 x 320 Resolution STN Positive Type from wholesalers
    • Buy cheap 40 Pins TFT LCD Resistive Touchscreen 4.6 Inch 800 x 320 Resolution STN Positive Type from wholesalers

    40 Pins TFT LCD Resistive Touchscreen 4.6 Inch 800 x 320 Resolution STN Positive Type

    Ask Lasest Price
    Brand Name : Fangsheng
    Model Number : FS046QWXH01CT-G
    Certification : ISO9001:2015
    Price : Negotiation
    Payment Terms : T/T,Western Union, Paypal
    Supply Ability : 200K Sets / Month
    Delivery Time : 10~15 Working Days
    • Product Details
    • Company Profile

    40 Pins TFT LCD Resistive Touchscreen 4.6 Inch 800 x 320 Resolution STN Positive Type


    40 Pin Touch Screen 4.6 Inch 800 x 320 TFT LCD



    Feature

    Details

    Unit

    Display Size(Diagonal)

    4.6"


    LCD type

    TN TFT


    Display Mode

    Normally White/Transmissive


    Resolution

    800 RGB x 320

    Pixels

    View Direction

    12 O’clock

    Best Image

    Gray Scale Inversion Direction

    6 O’clock


    Module Outline

    120.7 (H) x 57.08(V) x 3.10(MAX)(T)

    mm

    Active Area

    108 (H) x 43.2(V)

    mm

    Pixel Size

    135 (H) x 135(V)

    um

    Pixel Arrangemen

    R.G.B Vertical Stripe


    Polarizer Surface Treatment

    Anti-Glare


    Display Colors

    16.7M


    Interface

    24-bit RGB interface


    With or Without Touch Panel

    With CTP


    Operating Temperature

    -20~70


    ºC

    Storage Temperature

    -30~80

    ºC

    Weight

    42

    g


    Our Advantage:


    1 . Factory direct price.
    2 . Good quality.
    3 . Quick shipping within 5 days.
    4 . For stocks, no moq , 1pc ok . small order welcome..
    5 . Online payment.
    6 . Support 7 days refund.
    7 . After sales services 24 hours / 7 days


    Our Certificates:


    1 . GB/T19001-2016 idt ISO9001:2015
    2 . CE & ROHS
    3 . SGS of LCD Display


    PAYMENT


    Standard payment terms: pay 30% deposit in advance, 70% balance before shipment.

    Online trade assurance order, all is up to you.

    More payment terms could be provided (Visa, Mastercard)

    Quality 40 Pins TFT LCD Resistive Touchscreen 4.6 Inch 800 x 320 Resolution STN Positive Type for sale
